Monitor Audio Bronze W10 - Subwoofer Speakers

System Format

- Long-throw 10" driver featuring dished C-CAM cone. 10" flat panel ABR (Auxiliary Bass Radiator).
- 18 mm M.D.F. internally braced construction

Lower Frequency Limit

- -3 dB @ 33 Hz / -10 dB @ 28 Hz (Free Field) Default preset: Music, -3 dB @ 29 Hz / -10 dB @ 25 Hz (In Room)

Upper Frequency Limit

- -6 dB @ 150 Hz

Drive Unit Complement

- 1 x 250 mm (10") C-CAM subwoofer driver featuring a 2" long throw voice coil

Linear Driver Excursion

- 17 mm peak to peak

Amplifier Output

- 220 W

Amplifier Classification

- Class D with high current Switch mode power supply (SMPSU)

Phase Control

- 0 Degrees & 180 Degree pure Invert

Low Pass Filter Alignment

- 4th order (24 dB/Octave), from 50 Hz to 120 Hz

Equalisation DSP

- 3 pre-set modes: Music, Movie, Impact

Auto Sensing

- Line Level >3mV. Auto Standby feature after 20 mins

Audio Input/Outputs

- LFE unbalanced input RCA
- Stereo unbalanced inputs RCA

Input Impedance

- 20 kOhms input impedance

12 V Trigger

- 3.5 mm mono mini-jack. 6 V threshold

Electrical Certifications

- CE / CB / ETL / Fcc / CCC / ErP (Energy saving compliant)

Mains Input Voltage

- 110 120 Vac 50 60 Hz / 220 240 Vac 50 60 Hz (Manually selected)

Power Consumption

- Maximum 300 W, Standby <0.5 W (ErP compliance)

Fuse Type

- 20 mm T4AL 250 VAC

External Dimensions (Including Amp, Drivers and Terminals (H x W x D))

- 321 x 321 x 364 mm (125/8 x 125/8 x 145/16")

External Dimensions (Including Amp, Drivers, Terminals and Feet (H x W x D))

- 366.5 x 321 x 364 mm (147/16 x 125/8 x 145/16")

Weight (unpacked)

- 13.4 kg (29 lb 9 oz)

Sold As

- Single Unit
